Gill Instruments Ltd
Intrinsically Safe WindObserver Anemometer Page 8 Issue 10
Doc. No. 1360-PS-0001 May 2015
4.2 Power Supply Unit 1360-PK-053.
Mounted in Non Hazardous Area.
The I.S. PCI may be used with either Model 1360 IS Anemometer (SIRA 00ATEX2218, IECEx SIR
13.0157) or IS II Anemometer (SIRA 15ATEX2014 and IECEx SIR 13.0013).
I.S. Rating – ATEX European, IECEx International.
NOT for use in Zone 0, 1 and 2 Areas (Non Hazardous Area Use Only).
See ATEX and IECEx Certificates in Appendix 2.
Input and Outputs
Digital Input RS422 Interface (Data to/from IS WindObserver connected via
galvanic isolation).
Digital Outputs RS232 and RS422 Interface (Data to/from IS WindObserver)
Power Requirement
Input Power 100Vac - 120Vac, 10VA for the 115V switch position.
200Vac - 250Vac, 10VA for the 230V switch position.
Output Power 10.5v dc at 50mA to IS WindObserver (fused 100mA)
Dimensions
Size See this manual Page 11 for dimensions
Weight 9.5kg.
Materials
External Construction Stainless Steel 316
Environmental
Moisture protection IP65
Ambient Operating temperature -30°C to +40°C
Storage Temperature -50°C to +75°C
Humidity 5% to 90% RH
EMC EN 61000-6-3:2007
EN 61000-6-1:2007
Intrinsic Safety
EN60079-0:2012
EN60079-11:2012
IEC60079-0:2011 Edition 6.0
IEC60079-11:2011 Edition 6.0
Low Voltage Directive EN61558-1:1997
EN61558-2-6:1997
Standards Traceable to UK national standards
Site Calibration None required.
