Chapter 7 Operation Instructions and Parameter Setting
7.1 Main Menu
Fig. 7-1
【Operating instructions】
1. Enter corresponding setting interface by touch screen.
2.Use "Up""Down""Left""Right" to move the focus to the wanted submenu and press confirm
key or touch to enter corresponding interface.
3.Click
or press return key to return the sample interface.
7.2 Sample Interface
The interface is shown as Fig.7-2.
【Function introduction】
This interface shows waveform. You can modify gain, speed, print mode, waveform display
mode (3-lead, 6-lead, 12-lead), in addition print, set filter quickly, check sate of SD-card.
Operating instructions are as follows:
Fig. 7-2
State of Battery
To Next Page
