Glendinning EEC4 User Manual

EEC4 Installation Manual
StartInterlock
(Deutsch2pos.)
CPEnd
Duetsch4pos.Black
DCPowerHarness 30'long(9meters)
BatteryPositive#1
(Redwire)
BatteryPositive#2
(Redwire)
BatteryNegative
(yellowwire)
(NoiseSupressiondevices)
Connectoristhe
sameonbothends
StationCable 20ft.long 6meters
StationCable 30ft.long 9meters
StationCable 40ft.long 12.2meters
StationCable 60ft.long18.3meters
ETSControlSystemHarnesses-Cummins
TerminatingResistor
ControlProcessEnd
Duetsch12pos.Grey
Throttle/Gear/StartInterlock/CPEnableHarness 20'long(6meters)
SolenoidValve
Connectors
-withLEDindicators
BattPos.
Batt.Neg.
CumminsThrottle
InputConnector
(Packard3pos.)
ControlProcessEnd
Duetsch8pos.Black
StartUpEnable
(Deutsch4pos.)
Aux.Jumperfrom
engineconnector
installedhere
(Deutsch4.pos.
receptacle)
(DINtypeshown
Metripackoptional)
18
