Section 2.0 — Appendix / Reference
Gear Delay Options
The Gear Delay Option allows you to configure the EEC system to remain in gear when the system
goes from the throttle range to neutral, to allow throttle to reach idle before shifting transmission.
Configurable
0-2.5 second
Delay
Moving handles from the
throttle range (above idle)
into neutral . . .
RPMs decrease to idle . . . while transmission
pauses . . .
(Default = 0 seconds)
Neutral
Throttle
range
Throttle
range
before shifting transmission
into Neutral.
Press ACTIVE
5 times for
Gear Delay
Option
WARM LED will begin to flash
Press
WARM to
activate
selection
NO LEDs will be illuminated
Press
WARM to
save option
selection
You may continue to other configuration options
on the following pages or you may choose to
EXIT CONFIGURATION MODE by turning
system OFF, moving control handles back to
NEUTRAL, and then turn system ON again.
Press &
Release
ACTIVE
to cycle
through Gear
Delay Options
1
2
3
4
5
ACTION
LEDs ON AMOUNT OF DELAY
None None (Default)
Port Neutral 0.5 second
Active 1.0 second
Port Neutral & Active 1.5 second
Warm 2.0 second
6
Port Neutral & Warm 2.5 second
RESULT
To Change Gear Delay Setting Follow These Steps:
Enter Configuration Mode as described in section 2.4A (pg. 29)
To Next Page
