GB-750 Firewall Appliance Product Guide8
Hardware Specifications
Physical Specications
Chassis 1.75” h x 9” d x 19” w ( 4.45 cm x 22.7 cm x 48.25 cm)
Weight 8 lbs (3.63 kg)
Power Specications
MTBF (Mean Time Between Failure) Minimum–150,000 Hours
Input Voltage 95-135 VAC 180-265 VAC (Auto-switching)
Input Frequency 47Hz-63Hz
Operational Specications
Temperature 32° to 104° F (0° to 40° C)
Relative Humidity 10% - 90%, non-condensing
Storage Specications
Temperature 14° to 158° (-10° to 70°C)
Relative Humidity 5% - 95%, non-condensing
Memory
CPU 733 Mhz VIA C3
Memory 128 Mb
Flash Memory 64 Mb
I/O Interfaces
3 10/100 Ethernet interfaces. Ethernet 10Base-T on UTP
Cat. 3, 4 and 5, and Fast Ethernet 100Base-TX on UTP
Cat. 5. Interfaces 0, 1 and 2 are active and available.
2 RS-232 (DB-9). The Serial Console port should be set to
38,400 bps, 8 bit, 1 stop, no parity and ow control to
Hardware.
1 USB port. Reserved.
