GB-750 Firewall Appliance Product Guide8
1 – Introduction 9
VPN Acceleration
Chip Hi/fn 7951 security accelerator chip
Memory 128 KB high speed buffer
Throughput 64 Mbps
Compression LZS and MPPC at 43 to 99 Mbps
Encryption DES, Triple-DES and RC4 at 70 to 188 Mbps
Authentication SHA-1 and MD5 at 66 to 79 Mbps
Public Key, RSA and DH, 2 to 8 connections/sec using
1024 bit keys
Hardware random number generator
Form Factor Mini-PCI type III
Power 1.2 Watt Maximum
Operating 32° to 140° F (0 to 60 °C)
Temperature
Mounting
Use the supplied screws and mounting brackets to attach the system unit to
a standard equipment rack. Align the mounting bracket screw holes to the
chassis screw holes, insert the screws and tighten.
19” Rackmount Bracket
