Global Ultimate User Manual

4
ADDITIONAL ITEMS REQUIRED
o {1}Hitec 4 Channel Radio w/4 Servos
o {1}Dubro Foam Rubber # 513
o {1}Global Fuel Line # 115923
o {1}Dubro Fuel Filler Valve # 334
o {1}Goldberg 1/4” White Striping Tape # 724
o {1}Goldberg 1/8” Black Striping Tape # 711
o {1}Coverite 21st Century Red Paint # COVR0102
o {1}Coverite 21st Century Clear # COVR1265
FOR 2-STROKE ENGINE
o {1}Magnum XL .46-.53 Two Stroke
o {1}Pitts Style Muffler to Suite Engine
o {1}Magnum 2-1/2” Aluminum Spinner # 237154
o {1}Propeller To Suit Engine
o {1}Thunderbolt Glow Plug # 115493
FOR 4-STROKE ENGINE
o {1}Magnum XL .52-.80 Four Stroke
o {1}Magnum 2-1/2” Aluminum Spinner # 237154
o {1}Propeller To Suit Engine
o {1}Thunderbolt Glow Plug # 115490
TOOLS AND SUPPLIES NEEDED
o Kwik Bond Thin C/A # 887500
o Kwik Bond Thick C/A # 887510
o Kwik Bond 5 Minute Epoxy # 887560
o Kwik Bond 30 Minute Epoxy # 887565
o Pacer Canopy Glue # PT-56
o Pacer Thread Lock # PT-42
o Silicon Sealer
o Electric Drill
o Assorted Drill Bits
o Modeling Knife
o Machine Oil or Vaseline
o Rubbing Alcohol
o Paper Towels
o Straight Edge Ruler
o Dremel Tool w/Assorted Bits
o Robart Incidence Meter # 404
o Ernst Airplane Stand # 157
o Phillips Screwdriver
o Flat Blade Screwdriver
o Wire Cutters
o Pliers
o Builders Triangle
o 220 Grit Sandpaper
o Masking Tape
o Scissors
FIELD SUPPORT EQUIPMENT NEEDED
o Magnum 12V Electric Starter (# 361006)
o Magnum 12V Fuel Pump (# 237377)
o Magnum Locking Glow Clip (# 237440)
o Global 12V Battery (# 110171 )
o Global 12V Charger (# 110270 )
o Magnum Power Panel (# 237390)
o Global Field Buddy Flight Box (# 233072)
o Magnum 4-Way Wrench (# 237420)
METRIC CONVERSION CHART
To convert inches into millimeters: Inches x 25.4 = MM
1/64” = .4mm
1/32” = .8mm
1/16” = 1.6mm
3/32” = 2.4mm
1/8” = 3.2mm
5/32” = 4.0mm
3/16” = 4.8mm
1/4” = 6.4mm
3/8” = 9.5mm
1/2” = 12.7mm
5/8” = 15.9mm
3/4” = 19.0mm
1” = 25.4mm
2” = 50.8mm
3” = 76.2mm
6” = 152.4mm
12” = 304.8mm
18” = 457.2mm
21” = 533.4mm
24” = 609.6mm
30” = 762.0mm
36” = 914.4mm
OPTIONAL ITEMS
o {1}Williams Bros. 2-5/8” Pilot # 18500
o {1}Ernst External Charge Jack # 124
o {1}Cirrus On-Board Battery Indicator # 444762
