11.1 Format 0 of Report Messages
Format 0 report is prefixed by “GSr”. Its content is configurable by setting
parameter “O3”. Please refer to section 2.6 for the available report parameters
and the respective code words. Please collect the required code words and
put them together to form a string and set to “O3”. Then TR-206 will generate
report according to the codeword sequence and translate to corresponding
information.
Parameter’s Codeword
Description
O3
Report format 0
(Refer to “2.6. Parameters of Report Messages” for details of
parameters’ definition)
Example 1:
Set report format 0 by configuration message.
GSS,135785412249986,3,0,O3=SORPZAB27GHKLMN*U!*20!
Then format 0 report will be in the following format.
GSr,IMEI,Operation_mode,Report_Type,Alarm_Status,Geofence_status,GPS_
Fix,UTC_Date,UTC_Time,Longitude,Latitude,Altitude,Speed,Heading,Number_
of_Satellites,HDOP,Battery_capacity*checksum!
For example:
GSr,135785412249986,4,6,00,,3,230410,153318,E12129.2839,N2459.8570,0,1.17,
212,8,1.0,53*57!
Example 2:
Ask TR-206 report “format of format
0”
GSC,136647890362718,3,0,L1(O3)*6D!
TR-206 receives the command and reports the following message.
GSs,136647890362718,3,0,O3=SORPZAB27GHKLMN*U!*0b!
