11.2 Format 1 of Report Messages
Format 1 report is prefixed by “GSh”. Its content is configurable by setting
parameter “ON”. Please refer to section 2.6 for the available report
parameter and the respective codeword. Please collect the required
codeword and put
them together to form a string and set to “ON”. Then TR-206 will
generate report according to the codeword sequence and translate to
corresponding information.
Parameter’s Codeword
Description
ON
Report format 1
(Refer to “2.6. Parameters of Report Messages” for details of
parameters’ definition)
Example 1:
Set TR-206 format of report message for
format 1
GSS,131826789036289,3,0,ON=SPAN*U!*15!
Then format 1 report will be in the following format.
GSh,IMEI,Alarm_Status,GPS_Fix,Battery_capacity*checksu
m!
Example 2:
Ask TR-206 report “format of
format 1”
GSC,131826789036289,3,0,L1(ON)*
36!
TR-206 receives the command and report the following
message GSs,131826789036289,3,0,ON=SPAN*U!*66!
