73
11.3 Format 2 of Report Messages
GSM Cell ID is assisted information to get device location. When TR-206
does not get GPS fix, you could enable TR-206 to report the Cell ID
information. Then the report format of TR-206 will automatically switch
from format 0 to format 2 when TR-206 does not get GPS fix.
The parameter of enabling TR-206 to report the Cell ID is O8. Please note
that report format 1 is not affected regardless of the setting of O8.
Code word
Parameters
Value
Description
O8
Enable/ disable TR-206 to
1/0
0=disable
report “cell ID” if it does
not get GPS fix
1=enable
The report format (format 2) of cell ID is
GSd,IMEI,Device_Mode,Report_Type,Alarm_Status,Date,Time,Battery_capacit
y, “MCC1,MNC1,LAC1,CID1,BSIC1,RSSI1”,
“MCC2,MNC2,LAC2,CID2,BSIC2,RSSI2”,
“MCC3,MNC3,LAC3,CID3,BSIC3,RSSI3”,…*checksum!
MCC=mobile country code, 3 digits
MNC=mobile network code, 2 or 3 digits
LAC=location area code, 4 hexadecimal
digits. CID=cell identifier, 4 hexadecimal
digits.
BSIC=base station identity code, 1 digit or 2 digits.
RSSI=received signal strength indicator, 1 digit or 2
digits.
The number of set of cell information depends on GSM network
environment. The maximum number is 5.
For example:
GSd,131826789036289,4,5,00,260110,103255,"466,92,0A8D,08C6,13,14","466,92,
0A8D,2FD6,15,14","466,92,0A8D,466E,13,12","466,92,0A8D,6D7E,14,11","466,92
