Page 7
Loading/Unloading Labels
12. Push down on the lock lever until the print head locks into position.
13. With the scale plugged in and turned on, press the FEED key on the keypad once or twice in order to securely
turn the paper around the winding bobbin. Continue to press the FEED button until the labels are ejected
from the printer.
NOTE: If you receive an error message (ERR 9), it indicates that the label is not in the proper position. Press the
CLR key then press the FEED key again to feed the labels through the printer. You may need to do this
step a couple of times.
14. Close the side cover.
Unloading Remaining Label Roll
1. Open the side cover.
2. Release the printer head by pushing down on the release lever.
3. Pull the winding bobbin lever outwards to loosen the paper wound around the winding bobbin then remove
the paper from the winding bobbin.
4. Pull the stopper lever of the roll holder to make it straight then remove the label roll from the path and the roll
holder.
Release Lever
Winding Bobbin
Lever
Stopper Lever
Figure 7-1
Lock Lever
To Next Page
