Operating Instructions

 2.Torotatethebowlguardtoitsopenposition,grasptheseparatedhandlesonthebowlguardandmovethem,

 togetherasone,clockwisetoopen/rotatethebowlguard.Toclosethebowlguard,grasptheseparated

 handlesandmovethemtogetherasone,counterclockwisetoclose/rotatethebowlguardbackintoalocked

 position.

Removing and Attaching the Bowl Guard:

NOTE:Beforeremovingorattachingthebowlguard,makesurethebowlisinthedown/

loweredpositionandtheagitatortoolisofftheshaft.



 1.Toremovethebowlguardforcleaning,pushthelowerpartoftheseparatedhandle

 out(clockwise)dividingthehandleandreleasingtheguardfromtherotationring.

 (seeg.8-1)

 2.Onceseparated,takeholdofthelowerseparatedhandleandcontinueturningthe

 guardclockwiseuntilthebowlguardreleasesfromtheringcatchonthemixer.

 (seeg.8-2)

 3.Toreattachthebowlguard,lineuptheringcatchontheleftofthemixer;lift

 guardgentlyintoplaceandrotatetheguard’slowerhandlecounterclockwise

 untilitsnapsbackintoplacewiththeupperpartofthehandle.

ATTACHING THE BOWL TO THE MIXER

NOTE:InstallthebowlBEFOREattachingtheagitator.

1. Lowerthebowlbypullingthebowlliftleverforwardanddowntoitsresting

 position.FormodelsSP40andSP60rotatethebowlliftwheel

 counterclockwiseuntilitstops.FortheSP62PandSP80PLpressthedown

 arrow(bluebutton)tolowerthebowluntilitstops.

2. Liftthebowlbythebowlhandlesand:

 a. slowlypositionthelockingpin(locatedontherearofthebowl)intotheholeinthe

  middlerearofthecradle(seeg8-3).

 b. lowerthebowlontothepinslocatedoneithersideofthebowlcradle.

3. Oncethebowlispositionedonthecradle,securethebowlbypullingeachbowlclamp

 forwarduntilthebowlislockedtight(seeg8-4).

g.8-1

g.8-2

g.8-3 g.8-4
