4 Flue Options and Terminal Clearances
Diagram 4.1
Top horizontal telescopic ue (Ø60/100)
Part No. A2043600 - Section 10, page 21
Top horizontal standard ue (Ø60/100)
Part No. A2043400 - Section 10, page 25
Twin Flue
Twin Flue Adapter, concentric
ue (Ø80) Part No. A2011000
- Section 10, page 33
Plume Management
Kit basic set, white,
concentric ue
(Ø60/100) - Part No.
A2044100 for use with
Part No. A2043400 and
Part No. A2043600
- Section 10, page 36
Vertical Flue
Vertical Flue Adapter, concentric ue
(Ø60/100) Part. No. A2024600
Section 10, page 31
Vertical ue terminal kit, concentric
ue (Ø60/100) Part. No. 2000460480
Section 10, page 31
Direct rear telescopic ue (Ø60/100)
Part No. A2043500 - Section 10,
page 29
Ridge Tile Terminal
Part No. A2043800
- Section 10, page 30
Multiple Boiler Chimney Flue
Vertical concentric stack ue
suitable for use with:-
Top horizontal telescopic ue,
Top standard horizontal ue,
Twin Flue, as specied by the
manufacturer.
