GM Ultium PowerUP - Page 2

R 22MAR23
PART No.
SHEET
ALL INFORMATION WITHIN ABOVE
BORDER TO BE PRINTED EXACTLY
AS SHOWN ON 8.5 x 11 WHITE 16
POUND
NON-BOND RECYCLABLE
PAPER.
PRINT ON BOTH SIDES,
EXCLUDING TEMPLATES. TO BE
UNITED IN ACCORDANCE
WITH
GMCCA SPECIFICATIONS.
Date Revision Auth DR
Title
Ultium PowerUP Charge Station
User Manual
13DEC22 Fourth Re l SAR
PART No.
SHEET
MB
22MAR23
Fifth Re l
SAR
MB
84922762
29NOV22
Third Re l
SAR
AH
2
EN
CONTENTS
1. IMPORTANT SAFETY INSTRUCTION 3
2. GENERAL 3
2.1 STANDARD STATION FEATURES 4
2.2 CONNECTED FEATURES 4
2.3 MOBILE APP 4
2.4 INCLUDED IN THE BOX 5
2.5 INCLUDED IN THE ACCESSORY BOX 5
2.6 EQUIPMENT OVERVIEW 5
3. INSTALLATION INSTRUCTIONS 6
3.1 WALL-MOUNTING INSTRUCTIONS 7
3.1.1 MOUNTING THE ULTIUM POWERUP CHARGE STATION 7
3.1.2 MOUNTING THE CABLE WALL MOUNT 8
3.2 HARDWIRE INSTALLATION 9
4. INDICATOR OVERVIEW 12
5. OPERATING INSTRUCTIONS 13
6. MAINTENANCE AND STORAGE INSTRUCTIONS 17
6.1 DISPOSAL 17
7. TROUBLESHOOTING 18
7.1 SOFTWARE 18
7.2 MOBILE APP 18
7.3 MANUAL RESETTABLE ERROR 19
7.4 HAZARDOUS ERROR 20
8. TECHNICAL DATA 21
9. OVERCURRENT AND SHORT-CIRCUIT PROTECTION 21
10. BLUETOOTH
®
22
11. SUPPORT 22
12. COMPLIANCE 22
13. FCC STATEMENT 22
14. FCC RESPONSIBLE PARTY 23
15. ISED COMPLIANCE STATEMENT 23
16. NATIONAL USAGE RESTRICTIONS 23
17. LIMITED WARRANTY 24
TO BE COMPLETED BY INSTALLATION ELECTRICIAN FOR CUSTOMER REFERENCE
SERIAL NUMBER:
BLUETOOTH PAIRING CODE:
TOGGLE SWITCH (PLEASE TICK): NEMA HARDWIRE
CIRCUIT BREAKER SIZE:
RECOMMENDED CURRENT SETTING:
