Fury X-3 Installaon and Operang Instrucons
INSTALLATION
Wall Mount Installaon
Wall mounng hangers with a pogo are available for
installaon. The gure illustrates the various parts for a
typical wall mount charger installaon:
Step 1. Bolt the Wall Mount Hanger to the Wall
Secure the wall mount hanger to the concrete wall through
the pre-drilled holes in the hanger. Ensure the two ns are
facing up. Mount to a solid concrete wall through holes using
bolts into wall anchors – check with professional installaon
personnel to determine proper mounng techniques for all
wall types.
Step 2. Hang the Charger on the Wall Mount
Hang the charger on the wall mount hanger so that the two
slits on the back of the charger line up with the two ns of
the hanger.
Step 3. Mount the Boom Brace to the Charger and Wall Step 4. Mount the Pogo Wall Bracket to the Wall
and Aach the Pogo
Top
Boom
Installaon must only be carried out by suitably qualied personnel and in accordance with current local and naonal wiring regulaons.
Baery leads should not be altered without prior consultaon with service personnel.
The charger should be sited in a cool, dry, well-venlated locaon away from corrosive fumes and humid atmospheres. Ambient temperature range
must be maintained between 32°F-104°F.
Ensure venlaon is not obstructed at the le air intake and right exhaust vents.
The charger is for indoor use only.
Before installaon, check that the charger has not sustained any damages during transit. Make sure the electrical rangs are suitable for both the
intended AC input supply and the DC output current and voltage for the baeries to be charged. Also ensure that the connector polarity is correct
and matches the polarity of the baery connector.
CAUTION – To reduce the risk of re, use only on circuits provided with branch circuit protecon consistent with the current indicated on theFactory
Charger Conguraon label and in accordance with the Naonal Electrical Code, ANSI/NFPA 70 or equivalent.
The circuit breakers rang should be based on the charger's maximum input current, as stated on the Factory Charger Conguraon label. (See the
Technical Specicaons page for more details)
