Product specications
11 kW 22 kW
Stationary wallbox/charging
station
According to EN IEC 61851-1:2019
Dimensions Approx. 15.5 x 26 x 11 cm
Weight 1.85 kg 2.34 kg
Connection cable
1.8 m, 5 x 2.5 mm²
for permanent connection
(type H07BQ-F)
1.8 m, 5 x 6 mm²
for permanent connection
(type H07BQ-F)
Connection Single-phase or three-phase
Rated voltage 230 V - 240 V (single-phase) / 400 V - 415 V (three-phase)
Nominal frequency 50 Hz
Power grid types TT / TN / IT
Standby power 3.1 W (LEDs dark) to 5.2 W (LEDs bright)
RFID 13.56 MHz
WiFi 802.11b/g/n 2.4 GHz / frequency band 2412-2472 Mhz
Cellular connectivity*
4G | LTE / 2G | EDGE / Supported bands: GSM900, GSM1800, LTE FDD: B1
B3 B5 B7 B8 B20 / Frequency Range: 800MHz - 2600MHz
Safety functions
11 kW 22 kW
DC protection module with DC
current detection and additional
AC detection
6 mA DC, 20 mA AC
(An RCD type A must be installed on the building side and a miniature
circuit breaker must be connected upstream. The local installation regulati-
ons must be observed).
Protection class I
Pollution degree
II
Anti-theft device Charging cable locking device
Access control
Can be activated if required. Authentication via RFID or APP possible.One
learned RFID chip is already included.
Input voltage Phase and voltage testing
Switching functions Testing of the switching functions
Ground check
For TT, TN grids
(deactivatable ground check for IT grid - Norway mode)
Current sensor 3-phase
Temperature sensors Regulation of the charging current in case of overtemperature
Grid-serving control Two data cables for connection to ripple control receiver
IP65
Protected against dirt and water, suitable for permanent
outdoor operation
go-e network operator API
For authorised access by the electricity grid operator to the go-e Charger
for grid-serving power control
Modbus TCP e.g. for grid-serving power control by the electricity v grid operator
Permissible ambient conditions
11 kW 22 kW
Installation site Indoors and outdoors
Operating temperature -25 °C to + 40 °C
Storage temperature
-40 °C to + 85 °C
Average temperature in hours Maximum 35 °C
Altitude Maximum 2,000 m above sea level
Relative humidity Not more than 95 % (non-condensing)
Impact resistance IK08
Charging capacity
11 kW 22 kW Remark
Single-phase
charging car¹
1.4 kW
to 3.7 kW
1.4 kW
to 7.4 kW
Country-specic limitations
need to be observed
Two-phase
charging car¹
2.8 kW
to 7.4 kW
2.8 kW
to 14.8 kW
Two-phase connection of the charger is not
possible
Three-phase
charging car¹
4.2 kW
to 11 kW
4.2 kW
to 22 kW
go-e Charger switches through the power
that is available at the connection
¹Charging power depending on the number of phases of the car‘s onboard charger
Charging capacity
11 kW 22 kW
Maximum charging power
11 kW
(16 A, 3-phase)
22 kW
(32 A, 3-phase)
Ampere and status display Readable via LED ring and app
By button and app
Adjusting charging power
Via charging current in steps of 1
ampere between
6 A and 16 A
Via charging current in steps of 1
ampere between
6 A and 32 A
Connection to vehicle
11 kW 22 kW
Type 2 socket (acc. to EN 62196-2) with mechanical locking device
(own type 2 cable required, available as accessory)
Vehicles with type 1 can be charged with adapter cable type 2 to type 1
(available as accessories)
* = go-e Charger Gemini 2.0
