go-e Controller User Manual

88 99
L1
L2
L3
N
5. Product overview
Ethernet 100 Mbit/s
i
Type plate
with serial number of the Controller
j
Color display (320 x 240 px)
f
WiFi-antenna 2.4 GHz
h
Power supply with
connecting clamp
g
Modbus RS485 x2
for later extensions
b
Inlets for current measurement
Sensors 1-3
a
4 keys for menu navigation
d
Brightness sensor
Display switches off automatically
e
Inlets for current measurement
Sensors 4-6
c
c
e
g
f
a
b
h
i
d
Back
j
1
3
2
6 Current transformers foldable, 100 A
with jack plug
WiFi antenna, self-adhesive
optionally connectable
go-e Controller
Data card
Ethernet flat cable 2 m
optionally connectable
3
4
5
Connecting clamp
2
1
6
4
6
5
6. Scope of delivery

go-e Controller Specifications

General

Enclosure	Plastic
Communication Interface	WiFi
Protocols	Modbus
Output Voltage	230 V
Frequency	50 Hz
Protection	Overcurrent, Overvoltage
