Go! Go! Elite Traveller Plus User Manual

APPENDIX I - SPECIFICATIONS
1
Varies with user weight, terrain type, battery amp-hour rating (Ah), battery charge, battery condition, tire type, and tire
condition. This specification can be subject to a variance of (+ or -) 10%.
2
Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+
or – ) 3 %.
3
Approximate overall inflated dimensions.
4
AGM or Gel-Cell type required. See IV. “Batteries and Charging.”
5
Tested in accordance with ASNI/RESNA, WC Vol 2, Section 4 & ISO 7176-4 standards. Results derived from theoretical
calculation based on battery specifications and drive system performance. Test conducted at maximum weight capacity.
NOTE: This product conforms to all applicable ANSI-RESNA testing requirements and ISO 7176 series EN12184
standards. All specifications subject to change without notice.
Model Numbers Elite Traveller Plus: SC53, SC54
Elite Traveller Plus HD: SC53HD, SC54HD
Maximum Safe Slope See figure 1.
Maximum Climbing Ability See figure 1.
Maximum Obstacle Climbing Ability 2 in. (5 cm)
Colors Red, Blue, Silver (interchangeable panels)
Overall Length
2
3-wheel: 40 in. (101.6 cm), 4-wheel: 40.25 in. (102.24 cm)
Overall Width
2
21.12 in. (53.64 cm)
Total Weight Without Batteries 3-wheel: 75 lbs. (34 kg), 4-wheel: 78.5lbs. (35.6 kg)
Heaviest Piece When Disassembled
(Front Section)
3-wheel: Rear Section (32.5 lbs./14.74 kg)
4-wheel: Front Section (35 lbs./15.88 kg)
Turning Radius
2
3-wheel: 34 in. (86.36 cm), 4-wheel: 45.75 in. (116.2 cm)
Speed (maximum)
1
Variable up to 4.5 mph (7.24 km/h)
Range Per Charge
1,5
Up to 13 miles (21 km) with 17 Ah batteries
Ground Clearance
2
3 in. (7.62 cm) at mid-frame
Weight Capacity Elite Traveller Plus: 300 lbs. (136 kg)
Elite Traveller Plus HD: 325 lbs. (147.42 kg)
Standard Seating Type: Foldable, Material: Black Vinyl
Drive System Rear-wheel drive, sealed transaxle, 24 volt DC motor
Dual Braking System Electronic, regenerative, and electromechanical
Tires
3
Type: solid (flat-free inserts)
Front: 2 in. x 8 in. (5 cm x 20.32 cm)
Rear: 3 in. x 9 in. (7.63 cm x 22.86 cm)
Battery Requirements
4
Type: Two 12-volt, deep-cycle
Size: 17 Ah
Battery Pack Weight 17 Ah: 33 lbs. (15 kg)
Battery Charger Off-board charger

Go! Go! Elite Traveller Plus Specifications

General

Maximum Speed	4 mph
Overall Height	36 inches
Number of Wheels	4
Seat Width	18 inches
Weight Capacity	300 lbs
Range Per Charge	14.5 miles
Overall Width	21 inches
Seat Depth	16 inches
Motor	24V DC
Batteries	2 x 12V
Warranty on Electronics	2 years
Warranty on Batteries	6 Months
Wheel Size	9 inches
Seat Height (from ground)	22.5 inches
Warranty on Frame	Lifetime
