9. Inverter Control (On/Off)
The following Go Power!® inverters can be turned on/off through the GP-PWM-30
when a modular 6p4c RJ11 type connector is used (included with an optional Go
Power!® inverter remote):
• GP-SW1000-12 • GP-SW2000-24
• GP-SW1000-24 • GP-SW3000-12
• GP-HS1500-12 • GP-SW3000-24
• GP-SW2000-12 • GP-ISW Series
*The GP-SW1500 Inverter is not compatible.
First, connect the inverter directly to
the battery (follow the installation
instructions included with the inverter).
Then, connect the modular cable
(found in the inverter remote box) to the
remote terminal of the inverter and to
the remote terminal of the GP-PWM-30
(marked with an AC Plug symbol).
Please change the switch of the inverter
to Position 2 (remote controlled).
Now, you can enable / disable the
connected inverter by holding down the
AC Symbol Button for 3 seconds.
The inverter is enabled when the AC
plug symbol appears on the display
and is disabled when it disappears.
Inverter battery ground must
be connected to the ground of
one of the batteries connected
to the charge contoller.
Note
page 17
