Go Power GP-PWM-30 User Manual

Installation Overview
1.2 Specications
Description Value Dimensions
(H x W x D):
Nominal System Voltage 12V 108×190×35 mm
4.25×7.48×1.38 in
Weight: 300g / 10.6 oz
Maximum Wire Gauge:
#4 AWG
Warranty: 5 years
• PWM Charging
• 3 Battery Charging
proles
• 4 Stage Charging
• Monthly Equalize option
• Displays Charging
Current, Battery Voltage
and Battery State of
Charge
• Reverse Polarity
protected
• Temperature
Compensated
• RoHS Compliant,
environmentally safe
• Accepts up to 488 watts
of solar at 12 volts
• Maximum Power Boost
Technology
Max. Solar Array Current
Battery 1
30 amps (amperage is reduced
above 122°F / 50°C)
Max Solar Array Current
Battery 2
30 amps (amperage is reduced
above 122°F / 50°C)
Battery 1 Voltage Range 6V – 15.5V
Battery 2 Voltage Range 6V – 15.5V
Max. Solar Voltage 28V
Operating Consumption
(Display backlight on)
16mA
Operating Consumption
(Display backlight off)
6mA
Bulk/Absorption Voltage
(Sealed/Gel, AGM, Flooded)
14.1/14.4/14.4V
(77°F/25°C ), 1 – 2h / Day
Float Voltage 13.7V (77°F/25°C)
Equalization Voltage 14.9V (77°F/25°C),
2h / 28 Day or V < 12.1
Temperature Compensation -13mV/ºF / - 24mV/ºC
Operating Temperature
Display Operating
Temperature
- 40 to 185°F / - 40 to 85°C
- 14 to 131°F / - 10 to 55°C
Humidity 99% N.C.
Protection Battery Reverse Polarity, Solar
Array Reverse Polarity, Over
Temperature, PV Short Circuit,
Over Current
The total rated Maximum Power Current (Imp) of the PV input should not exceed
30 amps. The GP-PWM-30 will limit PV current above 30 Amps. Although the GP-PWM-30
will accept PV current greater than 30 Amps for a short duration, damage may occur if the
GP-PWM-30 operates continuously with greater than 30 Amps of PV input.
page 4

Go Power GP-PWM-30 Specifications

General

Input Voltage	12 VDC
Max Input Current	30A
Efficiency	Up to 99%
Battery Types	AGM, Flooded, Lithium, Gel
Protection Features	Reverse Polarity, Short Circuit
