Godex RT730i User Manual

39
3 Printer Setting and Control
036
** The USB Host port on ‘’i’’ ‘’x’’ model printer is without ‘’HUB’’ function.
** The USB Memory Stick supports with ‘’FAT32’’Disk Format and up to 32GB only. The certified venders are Transcend,
Apacer, Patriot, Consair and Kingston.
* The download function for Graphic, Font, Label Format, DBF and Command files is operated by GoLabel of PC and
must go through the a ‘’i’’ ‘’x’’ model printer itself.
* On a PC, user may copy entire folder’’\LABELDIR’’ from USB memory stick to PC or vice-versa. Copy a sub-folder or
individual file in ‘’\LABELDIR’’ to PC or vice-versa is not supported.
USB Keyboard

When plug-in an USB keyboard to the printer, LCD panel will display “Standalone Mode”, press the “Enter” key
on keyboard and “Feed” key in the printer to entering to the dialog for “Recall Label” operation.

Only the sub-dialog “Recall Label” is able operating by keyboard as follow definition:
1. Press “ESC” key to exist from “Standalone Mode” or back to previous dialog
2. Press “F1”, it will let the printer from “Ready” mode entering into “Standalone Mode”
3. Press “Enter”, “Arrow” and “Alphabetic” keys as the usual in PC that will perform the key-in function of
“Recall Label” in “Standalone Mode”.
Scanner

When plug-in an USB scanner to the printer, LCD panel will display “Standalone Mode”, press the “Feed” key
in the printer to entering the dialog of “Recall Label” operation. User performs the “Recall Label” function interactively
through the LCD panel, 4 direction keys, Feed key and Scanner.

Scanner is using in “standalone Mode” to scanning the “Serial Number, Variable” and Print Quantity while the printer
prompts a message on LCD panel and wait for data input.

Godex RT730i Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	762 mm
Maximum printing width	105.7 mm
Display	LCD
Product color	Black
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	8 MB
Certification	CE (EMC), FCC Class A, CB, CCC, cUL
Internal memory	16 MB
Built-in barcodes	1D, 2D, Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Windows code pages supported	1250, 1251, 1252, 1253, 1254, 1255, 1257
Ribbon width	110 mm
Core diameter	25.4 mm
Ribbon length	300 m
Media thickness	0.06 - 0.2 mm
Maximum roll diameter	127 mm
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 85 %
Power requirements	100-240V, 50-60Hz
Compatible operating systems	Windows 2000, XP, Vista, 7, Windows Server 2003, 2008

Weight and Dimensions

Depth	280 mm
Width	210 mm
Height	186 mm
Weight	3000 g
