Godex RT730i User Manual

3 Printer Setting and Control
3.9 Dump Mode Begin
For make sure provide us correct information for check what commands sentfrom the PC or software, please following below
steps,
STEP 1, Let the printer enter Dump Mode
For Desktop printer (RT200i / RT700i series, with LCD)
Just press and hold the key until LCD Display shows “DUMP MODE ”, then release the key.
STEP 2. Make sure pinter ready for print a label
STEP 3. Send a label or commands which met problem to the printer
STEP 4. Printer will print out a label with letters and numbers, please take a picture on them and send us by email.
To cancel (get out of) the Dump Mode, please press the FEED key, and then the printer will
automatically print “OUT OF DUMP MODE.” This indicates that the printer is back to the standby mode.
40

Godex RT730i Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	762 mm
Maximum printing width	105.7 mm
Display	LCD
Product color	Black
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	8 MB
Certification	CE (EMC), FCC Class A, CB, CCC, cUL
Internal memory	16 MB
Built-in barcodes	1D, 2D, Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Windows code pages supported	1250, 1251, 1252, 1253, 1254, 1255, 1257
Ribbon width	110 mm
Core diameter	25.4 mm
Ribbon length	300 m
Media thickness	0.06 - 0.2 mm
Maximum roll diameter	127 mm
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 85 %
Power requirements	100-240V, 50-60Hz
Compatible operating systems	Windows 2000, XP, Vista, 7, Windows Server 2003, 2008

Weight and Dimensions

Depth	280 mm
Width	210 mm
Height	186 mm
Weight	3000 g
