GOK SBS - Function Check

Excess flow device SBS
7 / 10
INSTALLATION NOTE SBS LOW PRESSURE
Suitable high-pressure hoses must be used for connection to the gas cylinders.
INSTALLATION NOTE SBS MEDIUM PRESSURE
Table 1: Protection-compatible hose line length in metres with rated internal
diameter of 4.0 mm (± 0.5 mm tolerance range) pursuant to DIN 4815-1
Flow rate
3.0 kg/h
4.0 kg/h
6.0 kg/h
10.0 kg/h
12.0 kg/h
15.0 kg/h
Nominal
pressure
1.5 bar
15
-
30
8
-
16
2
-
7
3.0 bar
45
-
< 50
30
-
45
12
-
22
1.2
-
4
4.0 bar
< 50
45
-
< 50
20
-
40
4
-
10
2
-
7
Table 2: Protection-compatible hose line length in metres with rated internal
diameter of 6.3 mm (± 0.5 mm tolerance range) pursuant to DIN 4815-1
Flow rate
3.0 kg/h
4.0 kg/h
6.0 kg/h
10.0 kg/h
12.0 kg/h
15.0 kg/h
Nomial
1.5 bar
< 50
40
-
< 50
20
-
40
5
-
15
3
-
10
1.5
-
4
3.0 bar
< 50
45
-
< 50
20
-
40
10
-
30
5
-
20
4.0 bar
< 50
35
-
< 50
25
-
45
13
-
30
Table 3: Protection-compatible hose line length in metres with rated internal
diameter
of 9.0 mm (± 0.5 mm tolerance range) pursuant to DIN 4815-1
Flow rate
3.0 kg/h
4.0 kg/h
6.0 kg/h
10.0 kg/h
12.0 kg/h
15.0 kg/h
Nominal
pressure
1.5 bar
< 50 < 50 < 50 < 50
40
-
< 50
25
-
40
3.0 bar
< 50 < 50
4.0 bar
FUNCTION CHECK
The excess flow device SBS must be tested for functionality as follows:
Risk of injuries or fire!
Serious burns to the skin or damage to property.
Do not use an open flame to check for leaks!
1. Close the gas cylinder valve.
2. Detach the hose line from the consumer.
3. Use your thumb to close the hose line opening.
4. Slowly open the gas cylinder valve.
5. Hold pressed the knob of the excess flow device SBS for three seconds:
 excess flow device SBS is activated.
6. Remove your thumb from the end of the hose line:
 the excess flow device SBS responds, a “PLOP” sound can be heard,
 the gas supply is interrupted and only a small residual amount can escape from the
hose line.
7. Connect the hose line to the consumer.
8. Open the gas cylinder valve and perform LEAK TESTING.
Item 5 is not applicable to the automatic SBS, since it opens automatically after some
time.
