TECHNICAL SPECIFICATIONS
MAIN FEATURES
D/A Converter AKM AK4493 PCM up to 32bit/
768kHz and DSD512 native
Streamer Network Player PCM and DSD
Frequency response: 20Hz-20kHz +/-0.1dB
THD – Total Harmonzic Distortion: 0.001% max
Signal to Noise ratio: -125dB
Dynamic range: 120dB
Output impedance RCA/XRL: 50Ω
Preamp Stage Volume Control: enabled/disabled
DIGITAL INPUTS
•1x RCA coaxial PCM asynchronous up to 24bit/
192kHz
•2x TOS-optical PCM asynchronous up to 24bit/
192kHz
•1x AES/EBU balanced PCM asynchronous up to
24bit/192kHz
•1x USB-A port to feed USB flash memories,
FAT32/NTFS formatted playing DSD64 and PCM up
to 24bit/192kHz
•1 x USB-B asynchronous up to DSD512 and PCM
up to 32bit/384kHz
AUDIO OUTPUTS
DAC: Stereo RCA @1Volt and balanced XLR @2Volt
PREAMP: stereo RCA, balanced XLR; 1 headphone
6,3mm Jack on the front panel double gain
ANALOGUE INPUT
3.5mm mini jack
POWER
100-240V, 50/60Hz
Multiple Transformer proprietary power supply
Power consumption: 30W
EXTERNAL POWER SUPPLY
PSU-10 EVO: external inductive multi transformer
power supply (optional)
NETWORK CONNECTIVITY
LAN/WLAN (WiFi): 802.11b/g via RJ45 10/100Mbps
socket
Bluetooth: High Definition 5.0
HIGH QUALITY STREAMING
Airplay, Deezer, MQA, Qobuz, Roon, Spotify, Tidal,
vTuner
SUPPORTED AUDIO FORMATS (NETWORK)
up to PCM 24bit/192kHz:
AIFF (.aif, .aiff, .aifc)
ALAC
WAV (.wav) packed/unpacked
FLAC
MP3
DSD64: DSF, DFF
Apple Lossless
OGG
Monkey’s
DSD64: DSF, DFF
IMPORTANT: UpnP server must support DSD stream-
ing in order to stream DSD files.
SUPPORTED MEDIA SERVERS
All UPnP / DLNA / Roon
DIMENSIONS AND WEIGHT
200mm W 80mm H 260mm D
Weight: Kg. 4 net - Kg. 5 boxed
FINISHES
Brushed Aluminium available in Black, Silver or Gold
REMOTE CONTROL
Multifunctional remote control
APP
GN Control
6
