3
SYSTEM OPERATION
- on the screenConnection will last for 90 seconds or until on-the-hook icon is pressed . When communication ends,
LED will turn off and the system will become free. If vocal synthesis is enabled, a 'Communication is finished'
message will indicate that the call is over.
- If call transfer to your mobile phone has been programmed, you can cancel the transfer at any time from the monitor,
with it being necessary to communicate with the door panel from the main menu.
- Upon receiving the call, the image will appear on the screen of the master monitor (and slave 1, if it exists) without the
visitor knowing and icon displayed on the screen will blink green. To view the image from slave monitors 2 or 3,
press the screen for the image to appear. If the call is not answered within 45 seconds, LED will turn off and the
system will become free.
- To establish communication, press off-the-hook icon on the screen. Door panel LED willwill turn off and the led
turn on.
-
To make a call, the visitor must press the button of the apartment; an audible sound indicates that the call is being made
and LED will turn on. If vocal synthesis is enabled, a 'Call is in progress' message appears indicating that a call is being
made. At this moment, the apartment's monitors receive the call. If another apartment is called by mistake, press the button
for the correct apartment and the first call will be cancelled.
- 6 18Detailed operation of the monitor is described on pp. - .
- ,To open door ó of the door panel on the screenpress the corresponding icon during the call or communication
processes: one press will activate the lock release for seconds and LED will also turn on for seconds. If vocal
synthesis is enabled, a 'Door open' message will be indicated on the door panel.
3 3
is
CHARACTERISTICS
- .Door release 1 and 2 activation icons screen
- .Installer menu
-
Hands-free monitor.
- (m xim 50mA/12V ).Output to auxiliary call repeater a um dc
- Monitor ( bus).with simple installation non-polarised 2 wires
- .Configuration switches andto toassign the address define whether the monitor is master or slave
- 7" TFT colour screen
- .User menu
- Touch screen for access and selection of menu function.
- ."HZ" input for calls from apartment front door Up to 8 monitors/ apartments with push button "HZ" activated
at the same time (with system and monitors in standby).
Important:
- Wifi smartphone.transmission monitor to call transfer to mobile Only the master monitor can activate Wi-Fi
transmission. (FA-ART 7W ).power supply unit required for apartment
- eds.Notification l
- .Image and communication settings menu
TS5110 ART 7W
MANUAL
If you have the “S5110 ART 7W” villa kit with Soul door panel download
user manual from the next r i the link Golmar
, “TS5110 ART 7W (cód. 50122126)”
QR o n web:
h! ps://doc.golmar.es/search/manual/50122126
VERY VILLAIMPORTANT ( KIT: S5110 ART 7W)
QR
1
2
ART MONITOR7W/G2+
