golmar Art 4/G2+ User Manual

3
DESCRIPTION
- Photo/video pending viewing.
Fixed yellow: In standby without notification.
E. Microphone.
A. Speaker.
Fixed red: 'Do not disturb' mode activated.
- 'Automatic door opening' enabled.
D. 4.3” TFT colour screen.
The function of each button is shown on the monitor
screen with an icon located just above each button
(see pp. 5-21).
B. Function buttons to access and select menu
functions.
C. Monitor status LED:
Blinking red:
G. Slot for MicroSD card (not included).
Above this raised dot is the 'Start/end communication'
button.
Type: MicroSD Class 10 from 4GB to 128GB.
In call/communication:
F. Raised dots for the visually impaired.
Above this raised dot is the 'Door opening' button.
J. Installation terminals.
I. Configuration switches.
H. Wall mounting connector fixing (x4).
A
D
B
C
E
G
H
I
J
H
H
H
SA
GND
HZ
HZ
ON
1 2 3 4 5 6 7
8
BUS
F
BUS
12210430 V02Product Version:
MONITOR 4” ART 4/G2+
GOLMAR S.A. C/ Silici, 13 08940-SPAIN
WARNING To prevent fire or electric shock, do not expose this device to rain or moisture
To prevent electric shock, do not remove cover.
CAUTION No user serviceable parts inside. Refer servicing to qualified service personnel
MADE IN CHINA
SA
OFF = 0
DIP 1 to 5
DIP 8
Monitor address
EOL resistor
DIP 6,7
00 - Master
10 - Slave 1
01 - Slave 2
11 - Slave 3
GND
HZ
HZ
BUS
BUS
ON = 1
ART 4/G2+MONITOR
