Continued from previous page.
SPECIAL CODES
Video sources available on a monitor (configure only on the master monitor).
Visible Not isiblev Factory setting
Door panel 1 0111 0110 0111
Door panel 2 0121 0120 0120
Door panel 3 0131 0130 0130
Door panel 4 0151 0150 0150
C m ra 1 0141 0140 0140a e
C m ra 2 0181 0180 0180a e
C m ra 3 0171 0170 0170a e
C m ra 4 0191 0190 0190a e
.
Important: Only available with EL632-G2 + SE video module with 'V03' or later.
General door panels installations, available with EL632-G2+ SE with ’V04' or later.
To Note:ART4 LITE/G2+ monitor with V.02 or laterdefine whether the monitor is master or slave
( ):
Master lave lave lave Factory defaultS 1 S 2 S 3
0550 0551 0552 0553 0550 (master)
Automatic door opening upon reception of a call on a monitor (configure only on the master monitor).
Activated Deactivated Factory setting
0441 0440 0440
Do not show the image on the monitor when receiving a call from the door panel when the monitor is in 'Do not disturb'
mode.
ShowDo not show Factory setting
0481 0480 0480 (show image)
Enable/ disable the icon of the main menu in all monitors (building).
Enable Disable Factory setting
0541 0540 0541 ( )enable
Restore the door panel(s) SoulAccess with the master code to factory default: “1234".
All door panels Door panel 1 Door panel Door panel Door panel 42 3
8000 8001 8002 8003 8004
LED lights for night viewing (Door panel 1) during a call or communication process. (Configure only on the master
monitor).
Automatic OFFAlways ON Always Factory setting
0450 0451 0452 0450 (automatic).
Activation times of the outputs (Door panel 1). (Configure only on the master monitor).
Factory setting
Relay 1 From to0200 (0,5s) 0219 (10s)0205 (3s)
Rel 0300 (0,5s) 0319 (10s)0305 (3s)ay 2 From to
Configuration of the remote activation button (Door panel 1).(Configure only on the master monitor).Relay1
Factory setting
Delay From to0400 (0,5s) 0419 (10s)0403 (2s)
Configuration of the remote activation button (Door panel 1).(Configure only on the master monitor).Relay2
Factory setting
Delay From 5 to 5 50 00 (0,5s) 0 19 (10s)0 03 (2s)
LED lights for night viewing (Door panel ) during a call or communication process. (Configure only on the master2
monitor).
Automatic OFFAlways ON Always Factory setting
1450 1451 1452 1450 (automatic).
Activation times of the outputs (Door panel ). (Configure only on the master monitor).2
Factory setting
Relay 1 From to1200 (0,5s) 1219 (10s)1205 (3s)
Rel 1300 (0,5s) 1319 (10s)1305 (3s)ay 2 From to
*
( )
*
( )
*
( )
*
( )
*
( )
*
( )
*
( )
*
( )
Continued overleaf
*
( )
*
( )
