3
SYSTEM OPERATION
CHARACTERISTICS
-
Hands-free monitor ( also allows communication with a handset).
- 7" TFT colour screen.
- for access and selection of menu function.Push buttons/ hidden push buttons
- Monitor ( bus).with simple installation non-polarised 2 wires
- User menu.
- Installer menu.
- Image and communication settings .menu
- Output to auxiliary call repeater (maximum 50mA/12Vdc).
- "HZ" input for calls from apartment front door. Up to monitors/ apartments with push button "HZ" activatedImportant: 6
at the same time (with system and monitors in standby).
- Push button for Door release 1 and hidden push button for Door release 2.
- eds.Notification l
- call (1 to 128) end of line.Configuration switches to assign the address and
- Function codes to define whether the monitor is master or slave (default: master).
ART 7T/G2+ MONITOR
- To make a call, the visitor must press the button of the apartment; an audible sound indicates that the call is being made
and LED will turn on. If vocal synthesis is enabled, a 'Call is in progress' message appears indicating thatthe door panel
a call is being made. At this moment, the apartment's monitors receive the call. If another apartment is called by mistake,
press the button for the correct apartment and the first call will be cancelled.
- Upon receiving the call, the image will appear on the screen of the master monitor (and slave 1, if it exists) without the visitor
knowing and icon displayed on the screen green . To view the image from slave monitors 2 or 3, press the( color) one of
the buttons (located above the raised dots for the visually impaired) of the monitor to display the image. If the call is not
answered within 45 seconds, LED will turn off and the system will become free.the door panel
- To establish communication, press off-the-hook icon on the screenthe push button below shown or (you can also lift the
handset) will turn off and the led turn on. Door panel LED will .
- Connection will last for 90 seconds or until on-the-hook icon .the push button below shown on the is pressedscreen
or (hang up the handset only if communication has been established by lifting the handset).When communication
ends, LED will turn off and the system will become free. If vocal synthesis is enabled, a 'Communicationdoor panel
is finished' message will indicate that the call is over.
- , press theTo open door of the door panel icon or press the hiddenor push button below of displayed on the screen
push button below of icon displayed on the screen during the call or communication processes: one press will activate the
lock release for seconds and LED will also turn on for seconds. If vocal synthesis is enabled, a 'Door3 3 isthe door panel
open' message will be indicated on the door panel.
- Detailed operation of the monitor is described on pp. 6-2 .7
1
2
1
2
