COMMUNICATION SCREEN
ART 7T/G2+ MONITOR
This screen is displayed during communication process. icon displayed on the screen (during thered color
communication i leftprocess) n the top centre of the screen, the date and time are shown and, on the , the source
,
of the image is displayed (door panel 1 door panel , camera 1 camera )to 4 to 4 .
Press the hidden button below icon to access the image and monitor in communicationduring 3 seconds
volume settings menu. Go to the option to be modified by pressing the hidden button belowbutton/
corresponding icons / , change to the desired level by pressing the hidden buttons below
corresponding icons / and validate the changes made by pressing the button below icon , (see
p. 1 )7 to 18 .
1
2
In communication, press the button below icon staircase light activation (SAR-G2 SAR-12/24to " " + &
modules required).
2
Press the hidden button below icon to change the source of the image as long as the system has
more than one door panel or has an external camera connected and display has been activated (see
pp. 2 - ). It is possible to make the change during display, call and communication processes8 31 .
Press the button below icon to start audio communication with the door panel displayed or (hang up
the handset only if communication has been established by lifting the handset). Communication has
a maximum duration of 90 seconds. Once communication has ended, the screen will turn off# .
A few seconds after receiving a call, it automatically takes a photograph. In the top of the screen,right
icon is displayed and indicator will illuminate. Press the hidden button below icon to take a
picture.
If a Micro SD card is inserted, a 15-second video automatically starts recording a few seconds after
receiving the call. In the top of the screen, icon is displayed and indicator will illuminateright
(see p. to configure video recording mode). Then a short 1-second press on the hidden button10
below icon will take a photograph or a long -second press will record a video.3
Press the button below icon to activate the lock release (or device connected to the CV output of the
door panel) for 3 seconds(factory setting, programmable by the installer; see pp. 2 - . During8 31)
activation, indicator will illuminate.
Press the hidden button below icon to activate the lock release (or device connected to the relay output
of the door panel) for 3 seconds (factory setting, programmable by the installer; see pp. 2 - . During8 31)
activation, indicator will illuminate.
1
2
1 2
1
1
1
