SYSTEM OPERATION
21
Typical Package Cooling
Restrictor Orifice Assembly in Cooling Operation
In the cooling mode the orifice is pushed into its seat forcing refrigerant to flow through the metered hole in the center
of the orifice.
Indoor
Coil
Outdoor
Coil
Chatleff
Orifice
Assy
