Goodman GPH13 - 3-PHASE HKR4 HEAT KIT - 15 KW

45
WIRING DIAGRAMS
HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
GPH13[36-60]M24*
3-PHASE HKR4 HEAT KIT - 15 KW
TLHTR1FL
TLHTR2FL
TLHTR3FL
3 PH. 460V CIRCUIT 2
4
6 9 8 7 5 3 2 1
RS
M1
M2 M4
M3
WIRE CODE
PU PURPLE PK PINK OR ORANGE
GR GREEN
BR BROWN BL BLUE BK BLACK
COMPONENT CODE
TL RS
HTR
HEAT ELEMENT
THERMAL LIMIT
RELAY/SEQUENCER
HKR4-15
0140K00147 Rev. A
