Goodwe A-ES Series User Manual

43
03 OTHERS User Manual V1.6-2022-01-05
3.4.3 Grid Parameter Setting
For parameter, which used in grid support and protection function, adjustable requirement of
CA Rule 21, HECO 14H and IEEE1547, the relevant explanations and setting methods can obtain
by reading, <Parameter Adjustable Method Of Grid Support Utility Interactive Inverter>, the
document can be obtained by contacting the after-sales.
3.4.2 Auto-transformer Speccation
Technical Data GW9600A-TX
Max. Continuous Rated Power (L-N) (VA)*1 4800
Rated Voltage (Vac) 120/240V Split Phase
Rated Frequency (Hz) 60
Max Continuous Output Current Per Phase @ 120 V
(A)
40
Split Phase Imbalance Current @Rated Power (A) 40
Thermal Protection YES
General Data
Operating Temperature Range -31°F~140°F (-35°C ~60°C)
Relative Humidity 0~95%
Operating Altitude ≤13123ft (4000m)
Cooling Natural Convection
Noise (dB) <25
Weight <22kg
Size (Width*Height*Depth) 13.6*10.9*6.9in (345*277*174mm)
Mounting Wall Bracket
AC Conduit Size 1"
Protection Degree NEMA type 4X
Certications & Standards
Safety UL 1741
Time frame Steady-state measurements Transient measurements
Parameter
Minimum
measurement
accuracy
Measurement
window
Range
Minimum
measurement
accuracy
Measurement
window
Range
Voltage, RMS (± 1% V
nom
) 10 cycles
0.5 p.u. to
1.2 p.u.
(± 2% V
nom
) 5 cycles
0.5 p.u. to 1.2
p.u.
Frequency
b
10 mHz 60 cycles
50 Hz to
66 Hz
100 mHz 5 cycles 50 Hz to 66 Hz

Goodwe A-ES Series Specifications

General

Max. AC Output Power (kVA)	5.5
Number of MPPT Trackers	2
European Efficiency	97.5%
Max. Charging Power (kW)	5.0
Max. Discharging Power (kW)	5.0
Nominal AC Output Power (kW)	5.0
Frequency	50/60 Hz
Operating Temperature	-25°C to 60°C
