Goodwe GW10K-DT - Page 9

The records include error massage and error times（190520 15：30）. Error massage can
be Found in Table 4.3.
• View model name and reconfigure safety country:
From the error massage history item in the first level menu, short press the key once to
see model name.
If you want to change the safety country, please hold the key for 2 seconds, then the LCD
screen will go to the second level menu.
In the second level menu, short press the key can change the safety country. If you change
nothing in second level menu and without pressing button in 20 seconds ,then the
backlight of LCD will power off and return to the first level menu. If you change the
safety country ，the LCD screen will show:“Setting...”after 10 seconds then show :
“ Set Fail”or“Set OK”.
• View software version
From the model name item in the first level menu, short press the key once to see
software version.
The current software version can be shown in this menu.
Setting:
• Set language:
Short press the button to enter the Set Language menu. Long press（2s）the key to enter
the second level menu. Short press to browse the languages available. If you change
nothing in second level menu and without pressing button in 20 seconds , then the
backlight of LCD will power off and screen return to the first level menu. If you change
the Language，the LCD screen will show：“Setting...” after 10 seconds then show :
“Set OK” or “ Set Fail ”.
• Set time:
From the first level Set language menu, short press the key to enter the Set Time menu.
Long press（2s）the key to enter the second level menu. The initial display is
“2019-00-00 00:00”, in which the first four numbers represent the year（e.g 2000-2099）;
the fifth and sixth number represent the month（e.g 01-12）; the seventh and the eighth
numbers represent the data（e.g 01-31）. The remaining number represent the time.
Short press increase the number in current location, and long press to move the cursor to
next position. The inverter will store the time the time after 20 seconds without any key
operation, and the LCD will automatically return to the main menu and the backlight will
switch off.
• Set protocol:
The function is only used for service personnel, set wrong protocol could lead to commu-
nication failure.
From the first level Set Time menu, short press the key once to enters protocol display
menu. Press the Key for 25 to enter submenu. The circulatory submenu including two
protocols can be found. The protocol can be chosen by short pressing the key. The
inverter will store the chosen protocol without any action within 255 and LCD display will
automatically return to main menu when the backlight is off.
• MPPT function for Shadow:
1413
50Hz GridDefault
Lock
No Error
Utility Loss
190520 05：21
50Hz GridDefault
Language
Portuguese
Ipv= 4.1/ 4.1A
Pac=6000W
Vpv=325.5/325.5V
Pac=6000W
E-Total=533.17KWh
Pac=6000W
E-Today= 15.2KWh
Pac=6000W
Normal
Pac=6000W
First Level menu
Short press
Short press
Short press
Short press
Short press
Error History
Pac=6000W
GW 6K-DT
Pac=6000W
Ver:
V1.XX .XX .XX
Set Language
Pac=2595.5W
Set Time
Pac=6000W
WiFi Reset
Pac=6000W
Short press
Short press
Short press
Short press
Short press
Short press
WIFI
WiFi Reload
Pac=6000W
Long press 2S
Second Level menu
Long press 2S
Long press 2S
Long press 2S
Short press for
safety country select
Long press 2S
Short press
Short press
2000-00-00 00：00
2000-00-00 00：00
���
2000-00-00 00：00
Short press to set
The second number
Long press 2S
Long press 2S
Long press 2S
Long press 2S
Long press 2S
Short press to set
The third number
Short press to set
The last number
WiFi Resetting
Long press 2S
WiFi Reset OK
WiFi Reset Fail
Wait 25s
WiFi Reloading
Long press 2S
WiFi Reload OK
WiFi Reload Fail
Wait 25s
PF Adjust
Pac=6000W
Short press
Short press
Shadow MPPT OFF
Pac=6000W
Shadow MPPT ON
Pac=6000W
Power Limit OFF
Pac=6000W
Power Limit ON
Pac=6000W
Set Power Limit
XXX %
Set Modbus Addr
Pac=6000W
Disable
lagging 0.95
lagging 0.95
lagging 0.95
Short press to select
Leading Or lagging
Long press 2S
Long press 2S
Long press 2S
Short press to select
Number 8 or 9
Short press to select
Number 0~9
Set Power Limit
XXX %
Set Power Limit
XXX%
Set Power Limit
XX X%
Long press 2S
Long press 2S
Long press 2S
Long press 2S
Short press
Short press
Set Addr ：XXX
Set Addr ：XXX
Set Addr ：XX X
Long press 2S
Long press 2S
Long press 2S
Short press to select
Number 0~9
Short press to select
Number 0~9
Short press to select
Number 0 or 1
Short press to select
Number 0~2
Short press to select
Number 0~9
Short press to select
Number 0~9
Short press
Or
Long press 2S
Short press
Short
press
Or
Long press 2S
Short press
Short press
Long press 2S
Set time
Set MOBUS
adress
Vac=
230/230/230V
Iac=
11.1/11.1/11.1A
Fac=50.02HZ
Short press
Short press
Wait 10s
Set OK
Set Fail
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
Wait 10s
LVRT ON
Pac=6000W
Short press
Long press 2S
Set OK
Set Fail
LVRT OFF
Pac=6000W
Long press 2S
Or
Setting ...
Setting ...
Setting ...
Setting ...
Set OK
Set Fail
Setting...
Set OK
Set Fail
Set OK
Set Fail
Set OK
Set Fail
Setting ...
Wait 10s
RSSI : 0%
Pac=6000W
Grid Type
Pac=6000W
Delta Grid
Star Grid
Set OK
Set Fail
Setting ...
Short press
Long press 2S
Short press
Wait 10s
Long press 2S to set password,
the default password is “1111”
Pac=6000W
