75
10 Technical Parameters
User Manual V1.1-2022-12-20
Technical Parameters GW5K-BT GW6K-BT GW8K-BT GW10K-BT
Ingress Protection Rating IP66 IP66 IP66 IP66
DC Connector MC4 (4~6mm
2
)
AC Connector Feed-Through Terminal Blocks UW10
Environmental Category 4K4H 4K4H 4K4H 4K4H
Pollution Degree III III III III
Overvoltage Category DC II/AC III DC II/AC III DC II/AC III DC II/AC III
Storage Temperature (℃) -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85
The Decisive Voltage Class (DVC)
Battery: C
AC: C
Com: A
Mounting Method Wall Mounted
Certication
*5
Grid Standards VDE-AR-N4105, EN 50549-1 G98, G99 G100, CEI 0-21
Safety Regulation IEC/EN 62477
EMC
EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4,
EN61000-4-16, EN61000-4-18, EN61000-4-29
*1: According to the local grid regulation.
*2: Can be reached only if battery capacity is enough, otherwise will shut down.
*3: CAN communication is congured by default. If 485 communication is used, please replace
the corresponding communication line.
*4: No Back-up Output.
*5: Not all certications & standards listed, check the ocial website for details.
*6: For Belgium Max. Apparent Power Output to Utility Grid (VA): GW5K-BT is 5000; GW6K-BT
is 6000; GW8K-BT is 8000; GW10K-BT is 10000.
