19
03 Product Introduction
User Manual V1.6-2024-03-20
The inverter reserves a dry contact controlling port, which supports connecting additional
contactors to enable/disable the loads, such as household loads, heat pumps, etc.
The load control methods are as follows:
• Time control: set the time to enable/disable the loads, and the loads will be turned on or o
automatically within the setting time period.
• Switch control: when the control mode is ON, the loads will be enabled; when it is OFF, the
loads will be disabled.
• BACK-UP load control: the inverter has an integrated relay controlling port, which can control
the loads o or on. In o-grid mode, the loads connected to the relay port can be turned o
if the overload at BACK-UP is detected or the battery SOC value is lower than the battery o-
grid protection setting.
For more detailed instructions, please refer to the SolarGo User Manual.
Load Control
Inverter
Loads
Circuit breaker
N
L1
L2
L3
A1
A2
DO1+
DO1-
SolarGo
User Manual
