Goodwe SDT G2 Series - Dimension

9
User Manual V1.0-2022-01-17 03 Product Introduction
3.4.2 Dimension
Dimensions of GW4K-DT, GW5K-DT, GW6K-DT, GW10KT-DT:
433mm
354mm
147mm
200mm
45mm
Dimensions of GW8KAU-DT, GW10KAU-DT, GW15KAU-DT, GW20KAU-DT, GW17KT-DT, GW20KT-DT,
GW25KT-DT, GW25KT-DT, GW8000-SDT-20, GW10K-SDT-20:
Dimensions of GW8K-DT, GW10KT-DT, GW12KT-DT, GW15KT-DT:
433mm
354mm
155mm
200mm
45mm
120mm
110mm
120mm
511mm
415mm
175mm
