Goodwe SDT G2 Series - Page 33

29
User Manual V1.0-2022-01-17
06 Electrical Connection
NOTICE
For models: GW4K-DT, GW5K-DT, GW6K-DT, GW10KT-DT, GW12KT-DT, GW15KT-DT
L
4-10kW: 4mm²≤S≤10mm²
12-15kW: 6mm²≤S≤16mm²
4-10kW: 13mm≤Φ≤18mm
12-15kW: 18mm≤Φ≤25mm
40mm
1
2
3
5
4
1
2
1
2
3 4
5
0.6N·m
PE
L(L3)
N
1(L1)
N
PE
L1
L2
L3
2(L2)
4
4
L1
L2
L3
N
PE
1
2
3
L
