REMOVING AND REPLACING THE OVEN DOOR WITH A
SINGLE-AXIS HINGE (depending on the model)
a) Conventional closing
b) Soft closing system (GentleClose) – the system absorbs
the shock from door closing. It allows simple, quiet, and
smooth closing. A gentle push (to a 15° angle relative to
the closed door position) is enough for the door to close
automatically and softly.
If the force applied to close the door is too strong,
the effect of the GentleClose system is reduced or the
system will be bypassed for safety.
• Fully open the oven door and rotate the stoppers all the
way back – applies to conventional door closing (Figure 1).
• If the appliance is fi tted with the GentleClose system, fl ip
the door latches back to a 90°angle (Figure 2).
• If the appliance is fi tted with the GentleClose system,
slightly lift the door latches and pull them towards you.
• Slowly close the door until the latches are aligned with
the slots. Slightly lift the door and pull it out from both
hinge slots on the appliance.
• Then, completely open the door and rotate the attachment
clips back to their initial position. Slowly close the door and
check, if they close properly. If the door does not open or
close correctly, make sure whether the hinge notches are
correctly placed in their seat hinges.
fi gure 1
fi gure 2
fi gure 3
34
