Step 4: Rear Sandbox/Panel Support Board
1: The 2 x 4 x 47-3/8” Panel Support (offset holes down) attaches to the back side of the
Rear Corner Posts with two 5/16” x 4-1/2” hex bolts and two 5/16” washers.
2: The 2 x 6 x 86” Rear Sandbox Board (offset holes down) attaches to the back side of
the Rear Corner Posts with two 5/16” x 4-1/2” hex bolts and two 5/16” washers into the
topmost holes in the Rear Sandbox Board.
2 x 4 x 47-3/8”
Panel Support
(offset holes down)
2 x 6 x 86”
Rear Sandbox
Board (offset holes
down)
5/16” x 4-1/2”
Hex Bolt
5/16” Washer
5/16” x 4-1/2”
Hex Bolt
5/16” Washer
Corner Post # 3
(Rear - Left)
Corner Post # 2
(Front - Left)
Corner Post # 1
(Front - Right)
Corner Post # 4
(Rear - Right)
This is a view of the REAR of the play set.
