Step 33: Arched Side Top Boards
1: Place one Arched Side Top Board on each side of the play set at the top.
2: Attach each Arched Side Top Board through the top hole into the t-nut in the corner
post with 5/16” x 4-1/2” hex bolts and 5/16” washers.
3: Attach each Arched Side Top Board through the bottom hole into the corner posts
with 5/16” x 3-1/2” lag screws and 5/16” washers.
5/16” x 4-1/2”
Hex Bolt
5/16” Washer
5/16” x 3-1/2”
Lag Screw
2 x 6 x 47-3/8”
Arched Side Top Board
