6 . Quick Start
6.1 Unpacking
Open the printer package and check the printer parts according to packing list. If any parts
are missing or damaged, please contact the local distributor.
6.2 Power Cable Connection
1） Make sure the printer power switch is OFF;
2）The printer power jack is a 3-pin socket and for 12V DC power input. Please plug
the DC cord connector into the printer's power jack properly.
CAUTION:
■ When connecting or disconnecting the plug, always hold the plug but not the cord.
■ Avoid pulling the power cord, otherwise any damages may cause a fire or
electrocution.
■ Avoid placing the power cord around other over heated equipment to prevent power
cord melting, which may cause a fire or electrocution.
■ We recommend that you unplug the printer from the power outlet if no use it for a
long period
6.3 Data Cable Connection
1）Make sure the printer power switch is OFF.
2）Plug the data cable connector into the printer's interface properly.
3）Plug the other end of the data cable with the host computer.
CAUTION:
■ Please do not plug the data cable when the printer power is ON.
6.4 Media Installation
To install the sticker paper and label roll, please refer . Paper Roll Installation
7 、Power On Utilities
There are five power-on utilities to set up and test printer hardware. These utilities are
activated by pressing FEED button and PAUSE button.
7.1、 Self-Test
To start the printer self-test, please follow the below steps,
1. Turn off the printer power.
2. Make sure the paper roll is installed correctly and the printer top cover is closed.
3. Press the FEED button and turning on the printer power simultaneously. When the
self-test paper (chart 21) comes out, release the FEED button.
"4 ".
