3
2 、General Information
2.1 Introduction
GP-2120T is designed for real-time and batch label printing, which is applicable in the
field of transportation, logistics, post, retail sale, and etc. The printer can be connected
with other equipment with various interface cards, such as Serial, USB ,It supports
different paper media, including thermal paper roll, thermal label paper and sticker paper.
The printer provides direct thermal printing at selectable printing speed of 2.0, 3.0, 4.0
and 5.0 inches per second. It accepts roll feed, die-cut and fan-fold labels. All common
bar code formats are available. Font and bar codes can be printed in 4 directions and
in 1 to 10 times enlargement size. High performance and efficiency of label printing
save your time!
2.2 Main Features
● Support thermal paper roll, thermal label paper and sticker paper.
● Support printing media width from 20mm to 60mm.
● Auto paper adjusting function.
● Auto temperature control for durable printing.
● Module design for different application.
3 、Printer Parts
1- Top Cover 2- Base housing 3- Top Cover Open Button
4- 5- 6- Feed Button
7- Pause Button 8- Error Indicator 9- ONLINE/POWER Indicator
Release Paper Exit Label Exit
Thermal Barcode Printer
1
2
3
5
6
7
8
9
（ 1）
4
