GPRINTER GP-2120T - Page 5

4
10- Power Switch 11- Power Port 12- Cashdrawer Port
13- USB Port 14-Serial Port
15- Print Head 16- Paper Roll 17- 18- Paper Presence Sensor
19- Peel-off Roller Lever 20- Light Transmission Sensor Light Source
21- Paper Roll Spindle 22- Peel-off Spindle 23- Peel-off Roller
Limiting Block
Thermal Barcode Printer
