GPS Tracker GPS104 - Hardware Description

3
1. Summary
Working Based on existing GSM/GPRS network and GPS satellites, this product can locate
and monitor any remote targets by SMS or internet.
2. Applications
 Vehicle rental / Fleet management etc
 Powerful magnet + water-proof bag, adsorbing in the hidden place of car for tracking
secretly.
 Protect child / the old / the disabled / pet etc
 Provide peace-of-mind for businessmen
 Personnel Management
 Criminals Tracking
3. Hardware Description
3.1 Front face 3.2 Rear face
3.3 Side face
3.4 Bottom face
USB port for upgrade
firmware and charging
battery
SOS Button
Indicator
Built-in GSM/GPRS
antenna
Microphon
e
ON /OFF
