10 Diagrams
10.1 INSERT CABLE WIRING
GND
1/4" TRS PLUG
TIP
SLEEVE
To Felix Insert Jack
SEND
RETURN
1/4" TS PLUG
1/4" TS PLUG
To Outboard Input Jack
To Outboard Output Jack
GND
RING
10.2 EXTERNAL FOOTSWITCH WIRING
GND
1/4" TRS PLUG
TIP
SLEEVE
To Felix footswitch jack
BOOSTMUTE
RING
