Grace Felix User Manual

16
11 Specifications
GAIN RANGE (Input to DI Output)
CH1 MIC 21-62dB
CH1 Inst Low Gain: 3-44dB / High Gain / 21-62dB
CH2 Inst -1.5-36.5dB
Boost 0-9dB
THD+N 1kHz, 22Hz-22kHz BW (MIC Input to DI Output)
@ 20dB Gain +10dBu out <0.0045%
@ 40dB Gain +10dBu out <0.0050%
@ 60dB Gain +10dBu out <0.010%
INTERMODULATION DISTORTION - SMPTE/DIN 4:1 7kHz/50Hz (MIC Input to DI Output)
@ 40dB Gain +10dBu out <0.05%
NOISE - REFERRED TO INPUT CH1 MIC @60dB Gain 22Hz-22kHz BW
50Ω source <-128dB
CMRR @60dB Gain
100Hz >55dB
1kHz >75dB
10kHz >75dB
FREQUENCY RESPONSE (Input to DI Output)
Mic input @ 40dB Gain -3dB 20Hz – 65kHz
Inst input @ 20dB Gain -3dB 20Hz – 65kHz
I/O IMPEDANCE
CH1 MIC Input 8.1kΩ
CH1 Inst Input HI: 10MegΩ / MED: 1MegΩ / LOW: 10kΩ
CH2 Inst Input HI: 20MegΩ / MED: 1MegΩ / LOW: 332kΩ
Insert Input 10kΩ
DI Outputs 150Ω
Amp, Tuner, Headphone and Insert Outputs 150Ω
SIGNAL / PEAK LED METER
Green threshold -10dBu
Red threshold +10dBu
MAXIMUM INPUT LEVEL
CH1 MIC 0dBu
CH1 Inst Low Gain: +21dBu / High Gain: 0dBu
CH2 Inst +20.5dBu
MAXIMUM OUTPUT LEVEL - 100k Ohm load, 0.1% THD
DI Outputs Line: +20dBu / Mic: -6dBu
Amp, Tuner, Headphone and Insert Outputs +22dBu
High Pass Filter / Notch Filter
High Pass Filter 20Hz – 1kHz @ -12dB/octave
Notch Filter 20Hz – 1kHz, >-35dB, Q>1.0
EQ
Gain +/- 12dB
Low Frequency Low Range: 125Hz Shelving / High Range: 250Hz Shelving
Mid Frequency Low Range: 70Hz – 880Hz / High Range: 670Hz – 8kHz
Mid Frequency Q 0.5 – 5
High Frequency 2kHz Shelving
OUTPUT NOISE 22Hz-22kHz BW @ MIN Gain
CH1 MIC Input (50 ohms) to DI Output <-88dBu
CH1 Inst Input to DI Output <-88dBu
CH2 Inst Input to DI Output <-98dBu
EXTERNAL FOOTSWITCH
MUTE (TIP) Momentary – Normally Open – Switch to GND < 10Ω
BOOST / TOGGLE (RING) Momentary – Normally Open – Switch to GND < 10Ω
POWER CONSUMPTION
100-240VAC 50/60Hz 10 Watts Max
WEIGHT and DIMENSIONS
3.2lbs H3.0” x W9.5” x D5.5”
