15
10.6 CONNECTION DIAGRAM
PUSH
reverb
out input
tuner
out input
amp
input
FELiX connections
Nothing too terribly hard and fast here - just the basics about how to plug stu in and out of
your preamp. There are many ways to connect a huge array of instrument sources to FELiX. If
you aren’t sure about how something works, please have another look at your owner’s
manual, check out our website - www.gracedesign.com - or feel free to call us. We are always
glad to help out in any way we can. 1.303.823.8100, M-F, 9-5 MST
acoustic or electric instruments with pickups or internal mics plug into Ch1 or Ch2 inputs
instrument mic, vocal mic
plugged into mic input 1
external eects routed
through the insert
stage amp fed by amp out
monitor mixer, recorder, workstation, yadda fed by DI 2 output. Sourced by mix or Ch2
FOH mixer fed by DI 1 output. Sourced by mix or Ch1
stage tuner
fed by tuner out
external
footswitch
external footswitch to
control mute and boost
side panel headphone jack
plug FELiX into nice,
clean AC power
A
