Graco 015.050-DP - KEY TO DESIGNATION; PRODUCT RANGE

- 03 - B.6.20.44-P
F22.060.03, issued on 01.98
TECHNICAL DATA
KEY TO DESIGNATION
OF THE MODULES
PRODUCT RANGE
Reciprocating pump 015.050-DP
Reciprocating pump 020.035-DP
Reciprocating pump 025.008-DP
Reciprocating pump 030.020-DP
Reciprocating pump 030.050-DP
Reciprocating pump 040.035-DP
Reciprocating pump 060.020-DP
Operating mode:
pneumatic
Action: double-action oscillating
Pressure transmission ratio
z. B. 030 = 30:1
fluid flow volume in cm
3
/stroke
e.g. 050 = 50cm
3
/stroke
=
W = Wall construction
F = Mobile construction
H = Elevation construction
S = Stand construction
G = Container construction
Appendix
RECIPROCATING PUMP 30 . 050 - D P W
Detailed information about basic versions,
basic devices, complete devices and article numbers can
be found in sales catalogue 01.2044
DISPLACEMENT PUMP
RECIPROCATING PUMPS
COUPLINGS
AIR MOTORS
