Graco 015.050-DP - AIR MOTOR D160 S70

- 4 - B.6.20.44.-EO
F22.060.02, issued on.01.98
AIR MOTOR D160 S70
List of repair parts, Air motor control Part No. 79978 904103
Pos 180 2 off Flat packing 80 x 25 x 0.75
Pos 210 4 off O-ring 30 x 2 B
Pos 220 1 off Drive pin
Pos 250 1 off Flat slide 31,5 x 31,5
Pos 260 1 off Slide plate to slide 31,5 Note assembly position
List of repair parts, Air motor seals Part No. 79978 904352
Pos 40 2 off O-ring 150 x 3 B
Pos 90 1 off O-ring 148 x 6 B
Pos 160 1 off Grooved ring
G 30 x 45 x
12 5B
Pos 180 2 off Flat packing 80 x 25 x 0.75
List of repair parts, piston rod Part No. 79978 904154
Pos 70 1 off Parallel pin M16 x 30 PLAS
Pos 100 1 off Piston rod D30 L121
Single part, cylinder cover Part No. 77536 033016
Pos 10 1 off Cylinder cover D160
Single part, cylinder bottom Part No. 77542 038016
Pos 110 1 off Cylinder bottom D160
