3 - B.6.20.44.-EO
F22.060.03, issued on 01.98
AIR MOTOR D60 S70
List of repair parts, Air motor control Part No. 79978 904103
Pos 180 2 off Flat packing 80 x 25 x 0.75
Pos 210 4 off O-ring 30 x 2 B
Pos 220 1 off Drive pin
Pos 250 1 off Flat slide 31,5 x 31,5
Pos 260 1 off Slide plate to slide 31,5 Note assembly position
List of repair parts, Air motor seals Part No. 79978 904102
Pos.40 2 off O-ring 54 x 3 B
Pos 90 1 off O-ring 60 x 5 B
Pos 160 1 off Grooved ring G 12 x 24 x 7.5
Can only be fitted with set of
tools Item ID.
70705 017002
Pos 180 2 off Flat packing 80 x 25 x 0.75
List of repair parts, piston rod Part No. 79978 904105
Pos 70 1 off Parallel pin M 8 x 20 PLAS
Pos 100 1 off Piston rod D12 L131
Single part, cylinder cover Part No. 77536 033006
Pos 10 1 off Cylinder cover D60
Single part, cylinder bottom Part No. 77542 032002
Pos 110 1 off Cylinder bottom D60
AIR MOTOR D110 S70
List of repair parts, Air motor control Part No. 79978 904103
Pos 180 2 off Flat packing 80 x 25 x 0.75
Pos 210 4 off. O-ring 30 x 2 B
Pos 220 1 off. Drive pin
Pos 250 1 off Flat slide 31,5 x 31,5
Pos 260 1 off Slide plate to slide 31,5 Note assembly position
List of repair parts, Air motor seals Part No. 79978 904152
Pos 40 2 off O-ring 100 x 3 B
Pos 90 1 off O-ring 100 x 5 B
Pos 160 1 off Grooved ring
G 30 x 45 x
12.5B
Pos 180 2 off Flat packing 80 x 25 x 0.75
List of repair parts, piston rod Part No. 79978 904154
Pos 70 1 off Parallel pin M16 x 30 PLAS
Pos 100 1 off Piston rod D30 L121
Single part, cylinder cover Part No. 77536 033011
Pos 10 1 off Cylinder cover D110
Single part, cylinder bottom Part No. 77542 038011
Pos 110 1 off Cylinder bottom D110
